Yamaha E40J - Fuel Line

FUEL
4-3
6F65G11
Fuel system
Fuel line
6F64020E
No. Part name Q’ty Remarks
1 Clip 6
2 Fuel hose 1
3 Bolt 1 M6 × 25 mm
4 Fuel joint 1
5 Fuel hose 1
6 Fuel hose 1
7 Bolt 2 M6 × 40 mm
8 Fuel pump 1
9 Gasket 1
10 Nut 1
11 Bolt 1
12 Bracket 1
13 Fuel filter assembly 1
14 Fuel filter element 1
15 O-ring 1
16 Cup 1
17 Screw 3 ø6 × 30 mm
Not reusable
Not reusable
