Yamaha E40J - Page 45

6F65G11
4-4
9
8
7
6
5
4
3
2
1
Fuel line
6F64020E
No. Part name Q’ty Remarks
18 Intake silencer 1
19 O-ring 1
20 Screw 4 ø6 × 12 mm
21 Joint 2
22 Link lever 1
23 Pin 1
24 Choke rod 1
25 Collar 1
26 Link rod 1
27 Nut 4
28 Washer 4
29 Gasket 1
30 Carburetor assembly 1
31 Gasket 1
32 Solenoid coil 1 W model
33 Spring 1 W model
34 Bracket 1 W model
Not reusable
Not reusable
Not reusable
