POWR
5-17
6F65G11
Power unit
2. Remove the flywheel magnet.
cC
To prevent damage to the engine or tools,
screw in the flywheel puller set bolts
evenly and completely so that the fly-
wheel
puller plate is parallel to the flywheel mag-
net.
NOTE:
Apply force to the crankshaft end until the fly-
wheel magnet comes off the tapered portion
of the crankshaft.
3. Remove the Woodruff key.
Removing the electrical components
1. Remove the bracket 1. (WH, W: CDI
unit, starter motor, starter relay and recti-
fier)
2. Remove the base assembly 2.
3. Remove the spark plug caps from the
spark plugs, and then remove the ignition
coil 3.
Removing the throttle pulley assembly
1. Removing the throttle pulley assembly.
To Next Page
