Yamaha E40J - Lower Unit (E40 G)

LOWR
6-5
6F65G11
Lower unit
Lower unit (E40G)
6F66050E
21 N·m (2.1 kgf·m, 15.5 ft·lb)
26
26
9 N·m (0.9 kgf·m, 6.6 ft·lb)
No. Part name Q’ty Remarks
1 Lower unit 1
2 Check screw 1
3 Gasket 3
4 Drain screw 1
5 Screw 1
6 Dowel 2
7 Bolt 3 M6 × 16 mm
8 Special washer 3
9 Anode 1
10 Anode 1
11 Propeller 1
12 Shear pin 1
13 Washer 1
14 Propeller nut 1
15 Cotter pin 1
16 Bolt 6 M8 × 30 mm
17 Screw 1
Not reusable
Not reusable
