Yamaha E40J - Removing the Pivot Shaft

BRKT
7-13
6F65G11
Bracket unit
5. Install a new gasket and the muffler
assembly into the upper case.
Removing the pivot shaft
1. Remove the pivot shaft from the swivel
bracket by pulling the shaft off the brack-
et.
2. Remove the oil seal 1 and then remove
the bushing 2.
6F670035
6F670130
2
1
6F670135
