General information
1-7
2. Check that the positive and negative bat-
tery leads are securely connected.
Checking the outboard motor
mounting height
1. Check that the anti-cavitation plate is
between the bottom of the boat and a
maximum of 25 mm (1 in) a below it. If
the mounting height is too high, cavitation
will occur and propulsion will be reduced.
Also, the engine speed will increase
abnormally and cause the engine to over-
heat. If the mounting height is too low,
water resistance will increase and reduce
engine efficiency.
NOTE:
The optimum mounting height is affected by
the combination of the boat and the outboard
motor. To determine the optimum mounting
height, test run the outboard motor at differ-
ent heights
2. Check that the clamp brackets are
secured with the clamp screws.
Checking the remote control cables
(remote control model)
1. Set the remote control lever to the neutral
position and fully close the throttle lever.
2. Check that the throttle pulley 1 is in its
fully closed position, and check the pulley
is contact the fully stopper a on the
bracket.
3. Check that the shift lever 2 is in the neu-
tral position.
w
The shift/throttle cable joint must be
screwed in a minimum of 8.0 mm (0.31 in)
b.
NOTE:
Check the throttle valve fully open, after set-
ting the remote control cables.
