Yamaha E40J - Crankcase

POWR
5-25
6F65G11
Power unit
6F65090E
20 N·m (2.0 kgf·m, 15 ft·lb)
40 N·m (4.0 kgf·m, 29.5 ft·lb)
No. Part name Q’ty Remarks
1 Crankshaft assembly 1
2 Cylinder Block 1
3 Anode 1
4 Bolt 1 M6 × 16 mm
5 Oil seal 2
6 Oil seal 1
7 O-ring 1
8 O-ring 1
9 Oil seal housing 1
10 Circlip 1
11 Crankcase 1
12 Bolt 10 M10 × 55 mm
13 Bolt 4 M8 × 35 mm
14 Bracket 1
15 Bracket 1
16 Bolt 1 M8 × 35 mm
17 Engine hanger 1
Not reusable
Not reusable
Not reusable
Not reusable
Crankcase
