Yamaha E40J - Page 81

6F65G11
5-26
9
8
7
6
5
4
3
2
1
Crankcase
6F65100E
No. Part name Q’ty Remarks
1 Crank 3 1
2 Washer 4
3 Roller bearing 2
4 Connecting rod 2
5 Needle bearing 56
6 Circlip 4
7 Piston 2
8 Piston pin 2
9 Piston ring set 2
10 Crank pin 2
11 Crank 4 1
12 Ball bearing 1
13 Labyrinth seal 1
14 Roller bearing assembly 1
15 Crank 2 1
16 Crank 1 1
17 Ball bearing 1
Not reusable
Not reusable
Not reusable
