Yamaha E40J - Lower Unit (E40 J)

LOWR
6-27
6F65G11
Lower unit
Lower unit (E40J)
6F66010E
4 N·m (0.4 kgf·m, 3.0 ft·lb)
21 N·m (2.1 kgf·m, 15.5 ft·lb)
9 N·m (0.9 kgf·m, 6.6 ft·lb)
35 N·m (3.5 kgf·m, 25.3 ft·lb)
No. Part name Q’ty Remarks
1 Lower unit 1
2 Check screw 1
3 Gasket 3
4 Drain screw 1
5 Screw 1
6 Dowel 2
7 Bolt 1 M10 × 30 mm
8 Anode 1
9 Washer 1
10 Propeller 1
11 Washer 1
12 Washer 1
13 Propeller nut 1
14 Cotter pin 1
15 Gasket 1
16 Cooling water inlet cover 1
17 Screw 1
Not reusable
Not reusable
Not reusable
