Yamaha E40J - Upper Case, Pivot Shaft

BRKT
7-7
6F65G11
Bracket unit
6F67040E
No. Part name Q’ty Remarks
1 Bolt 3 M6 × 25 mm
2 Exhaust guide 1
3 Gasket 1
4 Bolt 4 M6 × 20 mm
5 Exhaust manifold 1
6 Gasket 1
7 Seal 1
8 Rubber seal 2
9 Pipe 1
Not reusable
Not reusable
Not reusable
Not reusable
Upper case, pivot shaft
