Yamaha E40J - Removing the Power Unit

POWR
5-15
6F65G11
Power unit
8. Turn the sheave drum 3 times in the
direction of the arrow shown, and then
remove the starter rope from the notch
e.
NOTE:
Pull the start-in-gear protection cable 0 while
turning the sheave drum as shown.
9. Pull the manual starter handle several
times to check that the sheave drum
turns smoothly and to check the starter
rope for slack. Repeat steps 4—8 if nec-
essary.
10. Pull the manual starter handle complete-
ly, then measure the starter rope length.
Adjust if the starter rope length is out of
specification.
Removing the power unit
NOTE:
It is recommended to loosen the flywheel
magnet nut before removing the power unit to
improve working efficiency.
1. Disconnect the start-in-gear protection
cable 1, and then remove the manual
starter.
2. Disconnect the neutral switch connector.
(WH)
3. Remove the choke link rod 2 and intake
silencer 3.
4. Disconnect the throttle link rod 4.
6F650110
e
0
6F650140
1
6F600120
6F600190
3
2
6F650160
4
f
6F650130
Starter rope length f:
1,300–1,500 mm (51.2–59.1 in)
