Yamaha E40J - Reed Valves

POWR
5-19
6F65G11
Power unit
6F65070E
4 N·m (0.4 kgf·m, 3.0 ft·lb)
No. Part name Q’ty Remarks
1 Intake manifold #1 1
2 Reed valve assembly #1 1
3 Gasket 1
4 Intake manifold #2 1
5 Reed valve assembly #2 1
6 Gasket 1
7 Gasket 1
8 Gasket 1
9 Bolt 2 M6 × 65 mm
10 Screw 4 ø5 × 12 mm
11 Clip 10
12 Hose 5
13 Bolt 7 M6 × 25 mm
14 Neutral switch 1 WH model
15 Arm 1
16 Collar 1
17 Bracket 1
Not reusable
Not reusable
Not reusable
Not reusable
Reed valves
