Yamaha E40J - Page 103

6F65G11
6-6
9
8
7
6
5
4
3
2
1
Lower unit (E40G)
6F66050E
21 N·m (2.1 kgf·m, 15.5 ft·lb)
26
26
9 N·m (0.9 kgf·m, 6.6 ft·lb)
No. Part name Q’ty Remarks
18 Cover 1
19 Screen 1
20 Cap 1
21 Screw 1
22 Bolt 6 M8 × 80 mm Y-transom model
23 Extension 1 Y-transom model
24 Circlip 1 Y-transom model
25 Bushing 1 Y-transom model
26 Dowel 2 Y-transom model
