Yamaha E40J - Page 104

LOWR
6-7
6F65G11
Lower unit
6F66060E
17
No. Part name Q’ty Remarks
1 Shift rod 1
2 Holder 1
3 Bolt 1 M6 × 10 mm
4 Boot 1
5 Water pump housing 1
6 Bolt 2 M8 × 55 mm
7 Woodruff key 1
8 Insert cartridge 1
9 Impeller 1
10 Seal 1
11 Gasket 1
12 Outer plate cartridge 1
13 Gasket 1
14 Oil seal housing 1
15 Gasket 1
16 Oil seal 2
17 Dowel 3
Not reusable
Not reusable
Not reusable
Not reusable
