Lower unit
3. Install the Woodruff key into the drive
shaft.
4. Align the groove in the impeller 5 with
the Woodruff key 6, and then install the
impeller onto the drive shaft.
5. Install the insert cartridge 7 into the
pump housing 8, and then apply grease
to the inside of the insert cartridge.
NOTE:
Align the insert cartridge projection a with
the hole b in the pump housing.
6. Install the seal 9, a new gasket q and
pump housing assembly w into the lower
case, tighten the bolts e.
NOTE:
When installing the pump housing, apply
grease to the inside of the housing, and then
turn the drive shaft clockwise while pushing
down the pump housing.
To Next Page
