General specification
Item Unit
Model
E40GMH E40GWH E40JMH E40JWH E40JW
Fuel and oil
Fuel type Regular gasoline
Engine oil 2-stroke outboard motor oil
Engine oil grade
NMMA-certified TC-W3
Gear oil type Hypoid gear oil
Gear oil grade (*1) API GL-4
SAE 90
Gear oil quantity cm
3
(US oz, 315 (10.65, 11.11)
lmp oz)
Bracket unit
Trim angle Degree 8, 12, 16, 20, 24
(at 12° boat transom)
Tilt-up angle Degree 67
Steering angle Degree 45 + 45
Drive unit
Gear shift positions F-N-R
Gear ratio 1.85 (24/13) 2.00 (26/13)
Reduction gear type Spiral bevel gear
Clutch type Dog clutch
Propeller shaft type Share pin Spline
Propeller direction (rear view) Clockwise
Propeller ID mark H G
Electrical
Battery minimum capacity (*2)
CCA/EN — 347 — 347
20HR/IEC — 40 — 40
(*1) Meeting both API and SAE requirements
(*2) CCA: Cold Cranking Ampere
EN: European Norm (European standard)
IEC: International Electrotechnical Commission
