Yamaha E40J - Page 61

6F65G11
5-6
9
8
7
6
5
4
3
2
1
Power unit
6F65030E
160 N·m (16 kgf·m, 115 ft·lb)
MH
No. Part name Q’ty Remarks
1 Flywheel magnet 1
2 Base assembly 1
3 Bolt 3 M6 × 40 mm
4 Oil seal 1
5 O-ring 1
6 Woodruff key 1
7 Bolt 3 M8 × 14 mm
8 Starter pulley 1
9 Nut 1
10 Washer 1
11 Pulser coil 2
12 Screw 4 ø5 × 24 mm
13 Charge coil 1
14 Screw 4 ø6 × 25 mm
15 Light coil 1
16 Screw 1 ø4 × 6 mm
Not reusable
Not reusable
