4-26
FRONT BRAKE
Removing the front brake master cylinder
* For MTN890
** For MTN890D
Order Job/Parts to remove Q’ty Remarks
Rearview mirror (right) Refer to “HANDLEBAR” on page 4-57.
Brake fluid
Drain.
Refer to “BLEEDING THE HYDRAULIC
BRAKE SYSTEM (ABS)” on page 3-15.
1 Brake fluid reservoir cap stopper 1
2 Brake fluid reservoir cap 1
3 Brake fluid reservoir diaphragm holder 1
4 Brake fluid reservoir diaphragm 1
5 Brake fluid reservoir bracket 1
6 Brake fluid reservoir 1
7 Brake fluid reservoir hose 1
8 Brake lever 1
9 Front brake light switch connector 2 Disconnect. (for MTN890)
2
3
4
6
3
6
9
8
5
7
1
*
*
*
*
**
**
**
1
New
New
S
3.5 N
•
m (0.35 kgf
•
m, 2.6 lb
•
ft)
T
.R.
7 N
•
m (0.7 kgf
•
m, 5.2 lb
•
ft)
T
.R.
16 N
•
m (1.6 kgf
•
m, 12 lb
•
ft)
T
.R.
4.0 N
•
m (0.40 kgf
•
m, 3.0 lb
•
ft)
T
.R.
1.2 N
•
m (0.12 kgf
•
m, 0.88 lb
•
ft)
T
.R.
1.2 N
•
m (0.12 kgf
•
m, 0.88 lb
•
ft)
T
.R.
1.0 N
•
m (0.10 kgf
•
m, 0.73 lb
•
ft)
T
.R.
6 N
•
m (0.6 kgf
•
m, 4.4 lb
•
ft)
T
.R.
1.2 N
•
m (0.12 kgf
•
m, 0.88 lb
•
ft)
T
.R.
30 N
•
m (3.0 kgf
•
m, 22 lb
•
ft)
T
.R.
