BASIC SERVICE INFORMATION
EAS20010
BASIC SERVICE INFORMATION
EAS30014
ELECTRICAL SYSTEM
Electrical parts handling
NOTICE
ECA22611
• Do not perform angle adjustment of the IMU
and battery box by pinching the washer
and related parts.
• When installing the IMU, apply a thin coat of
silicone grease onto the washer where con-
tacting the IMU grommet.
• When installing the IMU, use only a genuine
bolt and washer, and tighten the bolt to the
specified torque.
• Pay attention not to expose the IMU to
strong shocks, such as striking or drop-
ping it.
• Do not place any foreign objects in and
around the battery box.
• Do not obstruct breather opening “a” of the
IMU.
• Do not clean the breather opening and do
not blow it with compressed air.
• When replacing the collar or grommet, re-
place all four collars and grommets.
a
