Yamaha MT-09 2021 - Checking the Switches

8-53
ELECTRICAL COMPONENTS
EAS30549
CHECKING THE SWITCHES
Check each switch for continuity with the pocket tester. If the continuity reading is incorrect, check the
wiring connections and if necessary, replace the switch.
TIP
Refer to “CHECKING THE SWITCHES” in “BASIC INFORMATION” (separate volume).
MTN890
R/L
L/W
W/BW/GB/W
R/W
BR
R/L B L/WR/W
START
OFF
OFF
ON
RUN
Y/B Y
Y/B Y
G/B W/G B
W/L L/R W/Y
L/R Br/L
L/R
G
W/R
B/Y
L/R
B
L/Y
Y/B
L/RY G/B
WR
W/LW/Y
B
W/GBr/L
ON
OFF
ON
OFF
FREE
DOWN
UP
R
N
L
OFF
ON
ON
OFF
SET
10
1
2
4
3
5
6
8
9
11
12
13
7
1. Mode switch
2. Dimmer switch
3. Pass switch
4. Horn switch
5. Hazard switch
6. Turn signal switch
7. Clutch switch
8. Sidestand switch
9. Front brake light switch
10. Stop/run/start switch
11. Main switch
12. Neutral switch
13. Rear brake light switch
