Yamaha MT-09 2021 - Abs Coupler Location Chart

9-41
ABS (Anti-lock Brake System)
EAS32892
ABS COUPLER LOCATION CHART
(R)
(Gy)
(B)
BW
WB
BW
YBr
R/G R/G R/W B/W
Lg
L/W L/B G/W
Y
W/G W/R G/B
W
W/G W/B Sb/W
G/L W/Y W/L Br/L
B G/O Br/W Br/B GBr
WB
R/GY/B
R
L/W
B
B/W
W/G
GYL
R/B
Br
L/W
G/O W/Y
LBWY L/B
5
4
21
3
1. Meter assembly coupler
2. YDT coupler
3. ABS ECU coupler
4. Rear wheel sensor coupler
5. Front wheel sensor coupler
