ELECTRICAL COMPONENTS
EAS20089
ELECTRICAL COMPONENTS
3
2
1
4
6
5
7
8
9
10
13
15
14
16
17
18
19
11
12
1. ECU (Engine Control Unit)
2. Fuel pump
3. Relay unit
4. Radiator fan motor relay
5. Fuse box
6. Brake light relay (for MTN890D)
7. Starter relay
8. Gear position sensor
9. Shift sensor
10. Sidestand switch
11. AC magneto
12. Crankshaft position sensor
13. O
2
sensor
14. Purge cut valve solenoid
15. Front wheel sensor
16. Horn
17. Headlight control unit
18. Intake air temperature sensor
19. Clutch switch
