ELECTRICAL COMPONENTS
19
20
1
2
4
3
5
6
7
8
9
10
11
12
13
14
15
16
17
18
1. ABS ECU (Electronic Control Unit)
2. Throttle servo motor
3. Intake air pressure sensor 2
4. Intake air pressure sensor 1
5. Throttle position sensor
6. Injector
7. Accelerator position sensor
8. Front brake light switch
9. Main switch/Immobilizer unit
10. Ignition coil
11. Radiator fan motor
12. Coolant temperature sensor
13. Starter motor
14. Oil pressure switch
15. Neutral switch
16. Rear brake light switch
17. Rear wheel sensor
18. Rectifier/regulator
19. IMU (Inertial Measurement Unit)
20. Battery
