Yamaha MT-09 2021 - Rear Brake

4-37
REAR BRAKE
EAS20031
REAR BRAKE
Removing the rear brake pads
* Three Bond No. 1521.
Order Job/Parts to remove Q’ty Remarks
1 Screw plug 1
2 Brake pad retaining bolt 1
3 Rear brake caliper 1
4 Brake pad 2
5 Brake pad shim 2
6 Brake pad insulator 2
7 Brake pad spring 1
8 Bleed screw 1
9 Brake caliper bracket assembly 1
LT
S
S
S
S
*
22 N
•
m (2.2 kgf
•
m, 16 lb
•
ft)
T
.R.
17 N
•
m (1.7 kgf
•
m, 13 lb
•
ft)
T
.R.
2.5 N
•
m (0.25 kgf
•
m, 1.8 lb
•
ft)
T
.R.
7
8
3
1
2
6
6
5
4
5
5 N
•
m (0.5 kgf
•
m, 3.7 lb
•
ft)
T
.R.
27 N
•
m (2.7 kgf
•
m, 20 lb
•
ft)
T
.R.
9
