Yamaha MT-09 2021 - Crankcase

5-63
CRANKCASE
EAS20059
CRANKCASE
Separating the crankcase
* Following the tightening order, loosen the bolt one by one, and then retighten it to the specific torque and the
specified angle.
** YAMAHA Bond No. 1215B®
Order Job/Parts to remove Q’ty Remarks
Engine Refer to “ENGINE REMOVAL” on page 5-9.
Cylinder head Refer to “CYLINDER HEAD” on page 5-26.
Water pump Refer to “WATER PUMP” on page 6-11.
Oil cooler Refer to “OIL COOLER” on page 6-7.
Water jacket joint Refer to “OIL COOLER” on page 6-7.
Thermostat assembly Refer to “THERMOSTAT” on page 6-9.
Starter clutch
Refer to “GENERATOR AND STARTER
CLUTCH” on page 5-36.
Starter motor
Refer to “ELECTRIC STARTER” on page 5-
41.
Clutch housing Refer to “CLUTCH” on page 5-45.
Oil strainer Refer to “OIL PAN” on page 5-61.
(2)
(6)
(2)
(4)
(2)
(12)
E
E
LS
**
E
LT
LT
New
New
LS
New
New
E
E
E
E
LT
LT
LT
LT
LS
New
1st 25 N
•
m (2.5 kgf
•
m, 18 lb
•
ft)
16 N
•
m (1.6 kgf
•
m, 12 lb
•
ft)
*2nd
Specified angle 60°
T.R.
22 N
•
m (2.2 kgf
•
m, 16 lb
•
ft)
T.R.
1.8 N
•
m (0.18 kgf
•
m, 1.3 lb
•
ft)
T.R.
10 N
•
m (1.0 kgf
•
m, 7.4 lb
•
ft)
T.R.
13 N
•
m (1.3 kgf
•
m, 9.6 lb
•
ft)
T.R.
12 N
•
m (1.2 kgf
•
m, 8.9 lb
•
ft)
T.R.
17 N
•
m (1.7 kgf
•
m, 13 lb
•
ft)
T.R.
70 N
•
m (7.0 kgf
•
m, 52 lb
•
ft)
T.R.
1st 25 N
•
m (2.5 kgf
•
m, 18 lb
•
ft)
20 N
•
m (2.0 kgf
•
m, 15 lb
•
ft)
*2nd
Specified angle 60°
T.R.
10 N
•
m (1.0 kgf
•
m, 7.4 lb
•
ft)
T.R.
10 N
•
m (1.0 kgf
•
m, 7.4 lb
•
ft)
T.R.
24 N
•
m (2.4 kgf
•
m, 18 lb
•
ft)
T.R.
4.0 N
•
m (0.40 kgf
•
m, 3.0 lb
•
ft)
T.R.
17 N
•
m (1.7 kgf
•
m, 13 lb
•
ft)
T.R.
