4-2
GENERAL CHASSIS (1)
Removing the rear cover
Order Job/Parts to remove Q’ty Remarks
Rider seat
Refer to “GENERAL CHASSIS (1)” on
page 4-1.
Battery
Refer to “GENERAL CHASSIS (1)” on
page 4-1.
1 Seat bracket 1
2 Rear side cover (left) 1
3 Rear side cover (right) 1
4 Rear turn signal light coupler 2 Disconnect.
5 License plate light coupler 1 Disconnect.
6 Mudguard assembly 1
7 Lower fender cover 1
8 Tail/brake light coupler 1 Disconnect.
9 Tail/brake light 1
10 Cover 1
11 IMU (Inertial Measurement Unit) 1
12 IMU coupler 1 Disconnect.
13 Rectifier/regulator cover 1
14 Rectifier/regulator coupler 1 Disconnect.
15 Rectifier/regulator 1
13
3
1
8
5
15
9
10
2
6
(4)
7
14
4
11
(4)
(4)
(4)
(4)
12
7 N
•
m (0.7 kgf
•
m, 5.2 lb
•
ft)
T.R
.
7 N
•
m (0.7 kgf
•
m, 5.2 lb
•
ft)
T.R
.
7 N
•
m (0.7 kgf
•
m, 5.2 lb
•
ft)
T.R
.
2.0 N
•
m (0.20 kgf
•
m, 1.5 lb
•
ft)
T.R
.
7 N
•
m (0.7 kgf
•
m, 5.2 lb
•
ft)
T.R
.
1.5 N
•
m (0.15 kgf
•
m, 1.1 lb
•
ft)
T.R
.
4.0 N
•
m (0.40 kgf
•
m, 3.0 lb
•
ft)
T.R
.
1.0 N
•
m (0.10 kgf
•
m, 0.73 lb
•
ft)
T.R
.
