4-29
FRONT BRAKE
Removing the front brake calipers
Order Job/Parts to remove Q’ty Remarks
The following procedure applies to both of
the front brake calipers.
Brake fluid
Drain.
Refer to“BLEEDING THE HYDRAULIC
BRAKE SYSTEM (ABS)” on page 3-15.
1 Brake hose union bolt 1
2 Brake hose gasket 3
3 Brake hose 2
4 Reflector bracket 1
5 Reflector 1
6 Front brake caliper 1
3
1
25
6
4
New
30 N
•
m (3.0 kgf
•
m, 22 lb
•
ft)
T
.R.
35 N
•
m (3.5 kgf
•
m, 26 lb
•
ft)
T
.R.
3.8 N
•
m (0.38 kgf
•
m, 2.8 lb
•
ft)
T
.R.
