5-6
LUBRICATION SYSTEM CHART AND DIAGRAMS
1
2
3
45
6
7
8
1. Cylinder head
2. Intake camshaft
3. Exhaust camshaft
4. Oil passage to the cylinder head
5. Oil passage to the clutch chamber
6. Oil return passage from the cylinder head
7. Crankshaft
8. Main gallery
