5-17
CAMSHAFTS
Removing the camshafts
Order Job/Parts to remove Q’ty Remarks
Crankshaft end cover/Timing mark accessing
bolt
Refer to “GENERATOR AND STARTER
CLUTCH” on page 5-36.
1Holder 2
2 Timing chain cover 1
3 Timing chain cover gasket 1
4 Timing chain tensioner 1
5 Timing chain tensioner gasket 1
6 Intake camshaft cap 1
7 Exhaust camshaft cap 1
8 Camshaft cap 1
9 Dowel pin 6
10 Intake camshaft 1
11 Exhaust camshaft 1
E
123
4
(7)
7
8
(8)
(4)
(4)
9
9
9
9
11
10
New
5
New
10 N
•
m (1.0 kgf
•
m, 7.4 lb
•
ft)
T
.R.
10 N
•
m (1.0 kgf
•
m, 7.4 lb
•
ft)
T
.R.
12 N
•
m (1.2 kgf
•
m, 8.9 lb
•
ft)
T
.R.
10 N
•
m (1.0 kgf
•
m, 7.4 lb
•
ft)
T
.R.
10 N
•
m (1.0 kgf
•
m, 7.4 lb
•
ft)
T
.R.
24 N
•
m (2.4 kgf
•
m, 18 lb
•
ft)
T
.R.
6
M
