8-7
IGNITION SYSTEM
8. Check the stop/run/start switch.
Refer to “CHECKING THE
SWITCHES” on page 8-53.
NG→ Replace the handlebar switch (right).
OK↓
9. Check the neutral switch.
Refer to “CHECKING THE
SWITCHES” on page 8-53.
NG→ Replace the neutral switch.
OK↓
10.Check the sidestand switch.
Refer to “CHECKING THE
SWITCHES” on page 8-53.
NG→ Replace the sidestand switch.
OK↓
11.Check the relay unit (diode).
Refer to “CHECKING THE RELAY
UNIT (DIODE)” on page 8-58.
NG→ Replace the relay unit.
OK↓
12.Check the entire ignition system’s
wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-1.
NG→
Properly connect or repair the ignition sys-
tem’s wiring.
OK↓
Replace the ECU.
Refer to “REPLACING THE ECU (En-
gine Control Unit)” on page 8-56.
To Next Page
