8-37
SIGNALING SYSTEM
QSS (Quick Shift System) does not operate.
1. Check that the MIL does not come
on.
NG→ Repair the faulty parts.
OK↓
2. Check that the QSS is working un-
der normal QSS operating condi-
tions.
NG→
Check the QSS operating conditions ex-
plained in the owner’s manual and operate
the QSS accordingly.
OK↓
3. Make sure that the QSS is effec-
tive.
(Check whether the “QS ” icon
is displayed at the top of the me-
ter.)
NG→
Activate the QSS. (Set the QSS to a set-
ting other than “OFF”.)
OK↓
4. Are you operating while the
“QS ” icon is lit?
NG→
Operate while the “QS ” icon is lit.
OK↓
5. Is the transmission gear display
normal?
NG→ Repair the gear position sensor.
OK↓
6. Check the connection of the cou-
pler between the gear position sen-
sor and the ECU.
NG→ Connect the gear position sensor coupler.
OK↓
7. Are the clutch and neutral switches
normal?
NG→ Repair the switch if it is not normal.
OK↓
8. Check the shift sensor value in the
diagnostic mode.
2.5 V when the shift pedal is not be-
ing operated.
4.5 V when the shift pedal is
pressed fully in.
0.5 V when the shift pedal is
pushed fully up.
NG→ Replace the shift sensor.
OK↓
9. Check the entire signaling sys-
tem’s wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-29.
NG→
Properly connect or repair the signaling
system’s wiring.
OK↓
To Next Page
