9-106
P0107, P0108
Ground short circuit check “A”
Lines short circuit check “B”
Between intake air pressure sensor 1 coupler
“1” and ground
blue–ground
pink/white–ground
ECU coupler “3”
[P0108] blue–any other coupler terminal
[P0108] black/blue–any other coupler terminal
[P0107, P0108] pink/white–any other coupler
terminal
Intake air pressure sensor 1 coupler “1”
[P0108] blue–any other coupler terminal
[P0108] black–any other coupler terminal
[P0107, P0108] pink/white–any other coupler
terminal
Joint coupler “2”
[P0108] black/blue–any other coupler terminal
[P0108] black–any other coupler terminal
Gy
LLVP
P/WO/WY/LL/B
B/LB/LBr/WGy/GBr/LB/YL/W
W/YW/GG/WG/WLg/BL/WL/Y
L/W
WW
L/W
BB
L/B L/B Y/B Y/B
L/R L/R L/RL/RB/L
B
B/L
BBBBB
B
P/W
L
B
P/W
L
Gy
LLVP
P/WY/LL/B
B/LB/LBr/WGy/GB/YL/W
W/YW/GG/WG/WL/WL/Y
BA
3
**
2
1
1
3
*
*. MTN890
**. MTN890D
Is resistance ∞ Ω?
YES
→ Go to step 4.
NO
a. Replace the wire harness.
b. Turn the main switch to “ON”, and then check the condition of the DTC using the malfunction
mode of the YDT.
Is it in the “Recovered” condition?
YES
→ Go to step 7, and complete the service.
NO
→ Go to step 4.
To Next Page
