9-230
P1601
5. Defective sidestand switch.
• Execute the diagnostic mode. (Code 20)
• Shift the transmission into gear.
6. Malfunction in ECU.
• Replace the ECU, and complete the service.
Refer to “REPLACING THE ECU (Engine Control Unit)” on page 8-56.
7. Delete the DTC and check that the MIL goes off.
• Confirm that the DTC has a condition of “Recovered” using the YDT, and then delete the DTC.
Sidestand retracted ON
Sidestand extended OFF
Is check result OK?
YES
→ Go to step 6.
NO
a. Replace the sidestand switch.
b. Turn the main switch to “ON”, and then extend and retract the sidestand.
c. Check the condition of the DTC using the malfunction mode of the YDT.
Is it in the “Recovered” condition?
YES
→ Go to step 7, and complete the service.
NO
→ Go to step 6.
