YASKAWA SGD7W - Page 114

6.2 Servomotor Main Circuit Cables
6.2.2 Servomotor Main Circuit Cables for Servomotors with Holding Brakes
6-8
External Dimensions
Servomo-
tor Model
Connec-
tor Type
External Dimensions
Order Num-
bers of Main
Power Supply
Cable and
Holding Brake
Cable
Individual Cable Order
Numbers
SGM7G-
03 or -05
300 W or
450 W
–––
SGM7G-
09 or -13
850 W or
1.3 kW
Straight
Standard
Cable:
JZSP-UVA131-
-E
Flexible Cable:
JZSP-UVA141-
-E
• Main Circuit Power
Supply Cable
Standard Cable:
JZSP-UVA101-
-E
Flexible Cable:
JZSP-UVA121-
-E
• Holding Brake Cable
*2
JZSP-U7B23--E
Right-
angle
*1
Standard
Cable:
JZSP-UVA132-
-E
Flexible Cable:
JZSP-UVA142-
-E
• Main Circuit Power
Supply Cable
Standard Cable:
JZSP-UVA102-
-E
Flexible Cable:
JZSP-UVA122--E
• Holding Brake Cable
*2
JZSP-U7B24--E
SGM7G-
20
1.8 kW
Straight
Standard
Cable:
JZSP-UVA331-
-E
Flexible Cable:
JZSP-UVA341-
-E
• Main Circuit Power
Supply Cable
Standard Cable:
JZSP-UVA301-
-E
Flexible Cable:
JZSP-UVA321-
-E
• Holding Brake Cable
*2
JZSP-U7B23--E
Right-
angle
*1
Standard
Cable:
JZSP-UVA332-
-E
Flexible Cable:
JZSP-UVA342-
-E
• Main Circuit Power
Supply Cable
Standard Cable:
JZSP-UVA302-
-E
Flexible Cable:
JZSP-UVA322--E
• Holding Brake Cable
*2
JZSP-U7B24--E
Continued on next page.
*1. The lead installation direction is away from the load. Consult Yaskawa Controls Co., Ltd. for other lead direc-
tions.
*2. Flexible Cables are provided as a standard feature.
SERVOPACK end Motor end
L
L
SERVOPACK end Motor end
L
SERVOPACK end Brake end
L
Brake end Motor end
L
SERVOPACK end Motor end
L
SERVOPACK end Motor end
L
SERVOPACK end Brake end
L
SERVOPACK end Motor end
L
Brake end Motor end
