6.2 Servomotor Main Circuit Cables
6.2.2 Servomotor Main Circuit Cables for Servomotors with Holding Brakes
6-9
6
Cables and User-Assembled Wiring Materials for SGM7G Rotary Servomotors
SGM7G-
30
2.4 kW
(When
used in
combina-
tion with
the
SGD7S-
200A)
Straight
Standard
Cable:
JZSP-UVA631-
-E
Flexible Cable:
JZSP-UVA641-
-E
• Main Circuit Power
Supply Cable
Standard Cable:
JZSP-UVA601-
-E
Flexible Cable:
JZSP-UVA621--E
• Holding Brake Cable
*2
JZSP-U7B23--E
Right-
angle
*1
Standard
Cable:
JZSP-UVA632-
-E
Flexible Cable:
JZSP-UVA642-
-E
• Main Circuit Power
Supply Cable
Standard Cable:
JZSP-UVA602-
-E
Flexible Cable:
JZSP-UVA622--E
• Holding Brake Cable
*2
JZSP-U7B24--E
SGM7G-
30 or
-44
2.9 kW or
4.4 kW
Straight
Standard
Cable:
JZSP-UVA731-
-E
Flexible Cable:
JZSP-UVA741-
-E
• Main Circuit Power
Supply Cable
Standard Cable:
JZSP-UVA701-
-E
Flexible Cable:
JZSP-UVA721--E
• Holding Brake Cable
*2
JZSP-U7B23--E
Right-
angle
*1
Standard
Cable:
JZSP-UVA732-
-E
Flexible Cable:
JZSP-UVA742-
-E
• Main Circuit Power
Supply Cable
Standard Cable:
JZSP-UVA702-
-E
Flexible Cable:
JZSP-UVA722-
-E
• Holding Brake Cable
*2
JZSP-U7B24--E
Continued on next page.
*1. The lead installation direction is away from the load.
*2. Flexible Cables are provided as a standard feature.
Continued from previous page.
Servomo-
tor Model
Connec-
tor Type
External Dimensions
Order Num-
bers of Main
Power Supply
Cable and
Holding Brake
Cable
Individual Cable Order
Numbers
L
SERVOPACK end Motor end
L
SERVOPACK end Brake end
L
SERVOPACK end Motor end
L
Brake end Motor end
SERVOPACK end
Motor end
L
SERVOPACK end Brake end
L
L
SERVOPACK end Motor end
L
Brake end Motor end
