YASKAWA SIGMA-7 Series User Manual

xi
Programming
Manuals
Machine Controller
MP3000 Series
Ladder Programming
Manual
SIEP C880725 13
Provides detailed information on
the ladder programming specifica-
tions and instructions for MP3000-
Series Machine Controllers and Σ-
7-Series Σ-7C SERVOPACKs.
Machine Controller
MP3000 Series
Motion Programming
Manual
SIEP C880725 14
Provides detailed information on
the motion programming and
sequence programming specifica-
tions and instructions for MP3000-
Series Machine Controllers and Σ-
7-Series Σ-7C SERVOPACKs.
Σ-7-Series
Operation Interface
Operating Manuals
Machine Controller
MP2000/MP3000 Series
Engineering Tool
MPE720 Version 7
User’s Manual
SIEP C880761 03
Describes in detail how to operate
MPE720 version 7.
Σ-7-Series AC Servo Drive
Digital Operator
Operating Manual
SIEP S800001 33
Describes the operating proce-
dures for a Digital Operator for a
Σ-7-Series Servo System.
AC Servo Drive
Engineering Tool
SigmaWin+
Operation Manual
SIET S800001 34
Provides detailed operating proce-
dures for the SigmaWin+ Engineer-
ing Tool for a Σ-7-Series Servo
System.
Distributed
I/O Module
User’s Manual
MECHATROLINK-III
Compatible I/O Module
User’s Manual
SIEP C880781 04
Describes the functions, specifica-
tions, operating methods, and
MECHATROLINK-III communica-
tions for the Remote I/O Modules
for MP2000/MP3000-Series
Machine Controllers.
Continued from previous page.
Classification Document Name Document No. Description

YASKAWA SIGMA-7 Series Specifications

General

Encoder Resolution	24-bit absolute encoder
Pollution Degree	2
Cooling Method	Natural cooling or forced air cooling
Control Method	Vector control
Communication Protocols	EtherCAT, MECHATROLINK-III
Input Voltage	AC 200 V, AC 400 V
Rated Output	Varies by model
Safety Function	STO (Safe Torque Off), SS1 (Safe Stop 1), SS2 (Safe Stop 2), SLS (Safely Limited Speed), SBC (Safe Brake Control)
Power Supply Voltage	AC 200 V, AC 400 V
Rated Output Current	Varies by model
Protection Functions	Overload, overvoltage, undervoltage, overheat, short circuit
Operating Temperature	0°C to 55°C
Storage Temperature	-20°C to 65°C
Vibration Resistance	5.9 m/s² at 10 Hz to 55 Hz
Ambient Humidity	5% to 95% RH (non-condensing)
Altitude	Up to 1000 m
Installation	Panel mounted
