1.1 Product Introduction
1-2
1.1 Product Introduction
The FT70 features three built-in functions optimized for driving a gantry to provide an optimal
solution for problems with gantry mechanisms.
• Position Correction Table (minimizes wasted torque produced by mechanical differences to
improve cycle times)
• Synchronized Stopping (prevents mechanical damage if alarms occur)
• Position Deviation between Axes Overflow Detection (detects twisting of the machine frame
to prevent mechanical damage and provide a useful function for preventative maintenance)

YASKAWA SIGMA-7 Series Specifications

General

Encoder Resolution	24-bit absolute encoder
Pollution Degree	2
Cooling Method	Natural cooling or forced air cooling
Control Method	Vector control
Communication Protocols	EtherCAT, MECHATROLINK-III
Input Voltage	AC 200 V, AC 400 V
Rated Output	Varies by model
Safety Function	STO (Safe Torque Off), SS1 (Safe Stop 1), SS2 (Safe Stop 2), SLS (Safely Limited Speed), SBC (Safe Brake Control)
Power Supply Voltage	AC 200 V, AC 400 V
Rated Output Current	Varies by model
Protection Functions	Overload, overvoltage, undervoltage, overheat, short circuit
Operating Temperature	0°C to 55°C
Storage Temperature	-20°C to 65°C
Vibration Resistance	5.9 m/s² at 10 Hz to 55 Hz
Ambient Humidity	5% to 95% RH (non-condensing)
Altitude	Up to 1000 m
Installation	Panel mounted
