YASKAWA SIGMA-7 Series User Manual

xxvi
Compliance with UL Standards and EU Directives
Certification marks for the standards for which the product has been certified by certification bodies
are shown on nameplate. Products that do not have the marks are not certified for the standards.
 North American Safety Standards (UL)
* Only products with derating specifications are in compliance with the UL Standards. Estimates are available for those prod-
ucts. Contact your Yaskawa representative for details.
Product Model North American Safety Standards (UL File No.)
SERVOPACKs SGD7W
UL 61800-5-1 (E147823)
CSA C22.2 No.274
Rotary
Servomotors
• SGM7M
• SGM7A
• SGM7J
• SGM7P
• SGM7G
• SGMMV
UL 1004-1
UL 1004-6
(E165827)
Linear
Servomotors
• SGLGW*
• SGLFW*
• SGLFW2
• SGLTW*
UL 1004-1
UL 1004-6
(E165827)

YASKAWA SIGMA-7 Series Specifications

General

Encoder Resolution	24-bit absolute encoder
Pollution Degree	2
Cooling Method	Natural cooling or forced air cooling
Control Method	Vector control
Communication Protocols	EtherCAT, MECHATROLINK-III
Input Voltage	AC 200 V, AC 400 V
Rated Output	Varies by model
Safety Function	STO (Safe Torque Off), SS1 (Safe Stop 1), SS2 (Safe Stop 2), SLS (Safely Limited Speed), SBC (Safe Brake Control)
Power Supply Voltage	AC 200 V, AC 400 V
Rated Output Current	Varies by model
Protection Functions	Overload, overvoltage, undervoltage, overheat, short circuit
Operating Temperature	0°C to 55°C
Storage Temperature	-20°C to 65°C
Vibration Resistance	5.9 m/s² at 10 Hz to 55 Hz
Ambient Humidity	5% to 95% RH (non-condensing)
Altitude	Up to 1000 m
Installation	Panel mounted
