3.4 Position Correction Table Settings
3.4.4 Setting Method with the MEM_WR Command
3-23
Reference: Details of Settings with MEM_WR
(Write Memory: 1EH) Command
Data Format
Phases in which the Com-
mand can be Executed
2, 3
Command Clas-
sification
Common com-
mand
Asynchronous
command
Processing Time
Σ-7-Series
MECHATROLINK-
III Communica-
tions Standard
Servo Profile
Command Man-
ual (Manual No.:
SIEP S800001
31)
Subcommand Cannot be used
Byte
MEM_WR
Description
Command Response
01EH 1EH The MEM_WR command writes the data in virtual mem-
ory by specifying the initial address, the data size and
the data for writing.
This command provides an adjustment function equiva-
lent to that of the ADJ command of the MECHA-
TROLINK-II compatible profile.
Confirm the completion of the command execution by
checking that RCMD = MEM_WR (= 1EH) and
CMD_STAT.CMDRDY = 1, and also checking the setting
for ADDRESS, SIZE, MODE/DATA_TYPE and DATA.
In the following cases, an alarm will occur and the com-
mand will not be executed.
When the ADDRESS data is invalid: CMD_ALM = 9H
(A.94A)
When the MODE/DATA_TYPE data is invalid: CMD_ALM
= 9H (A.94B)
When the SIZE data is invalid: CMD_ALM = 9H (A.94D)
When the DATA data is invalid: CMD_ALM = 9H (A.94B)
When the conditions for executing the adjustment oper-
ation are not satisfied: CMD_ALM=AH (A.95A)
While editing using the SigmaWin or Digital Operator:
CMD_ALM = AH (A.95A)
For details, refer to the following manual.
Σ-7-Series MECHATROLINK-III Communications Stan-
dard Servo Profile Command Manual
(Manual No.: SIEP S800001 31)
1 WDT RWDT
2
CMD_CTRL CMD_STAT
3
4 Reserved. Reserved.
5
MODE/
DATA_TYPE
MODE/
DATA_TYPE
6
SIZE SIZE
7
8
ADDRESS ADDRESS
9
10
11
12
DATA DATA
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
