8-40
IM AQ6370D-01EN
8.7 Saving/Loading Program Data
Procedure
Programs created with the program function are saved in binary format.
CAUTION
Do not remove the USB storage medium or turn the power OFF while the USB
storage medium access indicator is blinking. This can damage the data on the
medium or the device itself. Also, always place a USB storage medium in the
removable state (following the procedure in section 8.1) before removing it.
Selecting the Method of Automatically Setting the File Name
Select the method of automatically setting the file name by referring to page 8-6.
Setting the Type of the File to Be Saved to PROGRAM
1.
Press FILE.
2.
Press the ITEM SELECT soft key. The soft key menu switches.
3.
Press the PROGRAM soft key. PROGRAM is selected, and the screen returns to
the previous stage.
4.
Press the WRITE soft key to display the program list and file list.
To Next Page
