8-28
IM AQ6370D-01EN
8.5 Saving/Loading Setting Data
Procedure
The measurement conditions set on the instrument and soft key set statuses are saved
in binary format.
CAUTION
Do not remove the USB storage medium or turn the power OFF while the USB
storage medium access indicator is blinking. This can damage the data on the
medium or the device itself. Also, always place a USB storage medium in the
removable state (following the procedure in section 8.1) before removing it.
Selecting the Method of Automatically Setting the File Name
Select the method of automatically setting the file name by referring to page 8-6.
Setting the Type of the File to Be Saved to SETTING
1.
Press FILE.
2.
Press the ITEM SELECT soft key. The soft key menu switches.
3.
Press the SETTING soft key. SETTING is selected, and the screen returns to the
previous stage.
4.
Press the WRITE soft key. The file list is displayed.
To Next Page
