YOKOGAWA AQ6370D - 11.2 External Dimensions

11-4
IM AQ6370D-01EN
11.2 External Dimensions
Unit : mm
(approx. inch)
426
12.3
12.3
20.8 221
14.8
458.8 32
(
0.48
) (
16.77
) (
0.48
)
(
0.82
) (
8.70
)
(
0.58
)
(
18.06
) (
1.26
)
REAR VIEW
If not specified, the tolerance is ±3%. However, in cases of less than 10 mm, the tolerance is ±0.3 mm.
AQ6370D-02, AQ6370D-12, AQ6370D-22
AQ6370D-01, AQ6370D-10, AQ6370D-20
