5-29
IM AQ6370D-01EN
Measurement
5
5.9 Sensitivity Settings
Procedure
1.
Press SETUP. The soft key menu for sweep condition settings appears.
2.
Press the SENS/MODE soft key. Seven sensitivity choices appear in the soft key
menu.
3.
Press the soft key corresponding to the desired choice. The screen returns to the
previous stage, and the value specified by the SENS/MODE soft key is displayed.
CHOP MODE Settings
2.
Press the SENS/MODE soft key.
3.
Press the CHOP MODE soft key.
4.
Press the SWITCH soft key.
5.
To turn CHOP MODE OFF, press the OFF soft key.
Note
If you set the CHOP MODE to SWITCH, the corresponding sensitivity soft key display will
change to MID/SW or HIGH1/SW to HIGH3/SW.
To Next Page
