4-1
IM AQ6370D-01EN
Common Operations
4
4.1 Description of Soft Keys
When you press a function key, the soft key menu (inside the screen) located on the right
side of the screen changes.
The soft key menus are designed to provide a certain level intuitiveness, with the
individual soft keys having particular forms which make them easy to understand.
Forms and Behavior
This is a normal soft key.
Press to execute its function immediately.
Contains a submenu.
Indicates that there is a submenu of additional items related to
the current item.
Press to display the submenu.
A separate window will be displayed.
Press to display a separate window in the screen for entry of
numerical parameters.
A submenu and separate window will be displayed.
Press to move to the submenu and display a separate window.
This softkey returns to the previous menu.
Press to display the previous soft key menu.
This is a selection soft key.
Select one of the soft keys connected with the black band.
When selected, the soft key is displayed in reverse video.
Several soft keys can be connected.
Chapter 4 Common Operations
To Next Page
