YOKOGAWA AQ6370D - Page 287

8-29
IM AQ6370D-01EN
Saving/Loading Data
1
2
3
4
5
6
7
8
9
10
11
App
Index
Selecting the Save Destination Medium
5.
Press the MEMORY soft key and specify INT (internal memory) or EXT (USB
storage medium). A file list of the selected medium is displayed.
Entering the Name of the File to Be Saved
If you do not set a file name, the file will automatically be assigned a name using a serial
number or date.
For creating a directory and sorting the file list, see the page 8-9.
6.
Using the
rotary knob or arrow keys, move the cursor to the line in the file list
displaying NEW FILE.
7.
Press the FILE NAME soft key. The text entry window and corresponding soft key
menu are displayed.
8
Follow the instructions in section 4.3 to enter a file name.
9.
Press the DONE soft key. The file name is confirmed, and the screen returns to
the previous stage.
Sets the file name
Creates a directory
Sorts the file list
8.5 Saving/Loading Setting Data
