4-6
IM AQ6370D-01EN
Entering Strings
Character strings can be entered from the character selection area displayed on screen
using the rotary knob and soft keys.
Entry Procedure
The following is an example of entering a label.
1.
Press DISPLAY. The soft key menu for the screen display appears.
2.
Press the LABEL soft key. The text selection area and label entry area are
displayed.
Move cursor to right
Move cursor to left
Insert character
Delete character
Delete all characters
Enter characters
Finalize entry
Discard changes
3.
Move the cursor to the character in the character selection area that you wish
to enter. Use the rotary knob or arrow keys to move the cursor in the character
selection area.
4.
Press the ENTER soft key. The character selected at the cursor position in the
label input area is displayed.
5.
To move the cursor, or insert or delete a character in the label input area, press
the corresponding soft key.
6.
When the character string is entered, press the DONE soft key. The input
character string is entered.
Note
• In addition to when pressing DISPLAY, the character input screen appears whenever a
string must be entered on the instrument, such as when entering a file name for saving a
file.
• Numerical input can be performed directly from the numeric key pad.
4.3 Entering Numerical Values and Strings
To Next Page
