Accessories 2 - 19
Figure 2-19 Connect Adapter Power Cable
7. Place adapter onto cradle base and slide toward rear of cradle.
Figure 2-20 Install Adapter
8. Using a Phillips screwdriver, secure adapter to cradle base with screw.
