Accessories 2 - 41
Figure 2-52 Insert Bottom of Battery into Battery Compartment
11. Rotate the top of the battery into the battery compartment.
12. Press the battery down into the battery compartment until the battery release latches snap into place.
Figure 2-53 Press Down on Battery
13. Place hand strap clip into hand strap mounting slot and pull down until it snaps into place.
Figure 2-54 Secure Hand Strap Clip
