7-161211-1020202 CenterMax Operating Instructions
Chapter
.................................................................................................................................
7 Measuring operation
Connections carried out, workpiece clamped on measuring table,
probe system prepared. The preparations for the measuring run can
begin.
This chapter describes the procedure for correct measurement with
the CMM. Furthermore, the possible causes of unusual measured
results are also explained.
This chapter contains:
What you should know! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Preparations for a measuring run . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Probing the workpiece . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Automatic probe change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Tips for effective operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Evaluating the measuring data. . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Terminating a measuring run . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
