6-14
Start-up
61211-1020202 CenterMax Operating Instructions
– perfect condition
– clean
– grease-free
• Observe the limiting values; probe length and probe weight.
Limiting values
The maximum weight and length must not be exceeded in order to
ensure error-free measurement by the probe system.
The limiting values depend on the probe system used.
Example
Connecting parts are usually required to assemble the required probe
configuration. It is also possible to screw the probe directly into the
adapter plate ➤ page 6-15.
Maximum values VAST
Probe weight – including
adapter plate
600g
Probe length – including
extension:
450mm
G
L
